Price Upon Request
FINANCING AVAILABLE
Overview
- Condition: New vehicle
- Manufacturer: Harley-Davidson
- Model: FLTRX
- Version: ROAD GLIDE
- Year: 2026
- Stock #: INS00029
- Type: Touring
- Exterior colour: Vivid Black
Specifications
- Length: 2,410 mm (94.9 in.)
- Overall Width: 945 mm (37.2 in.)
- Overall Height: 1,315 mm (51.8 in.)
- Seat Height, Unladen: 720 mm (28.3 in.)
- Seat Height, Unladen (Low seat position):
- Seat Height, Unladen (High seat position):
- Seat Height, Unladen (Low seat position with optional ARH suspension):
- Seat Height, Unladen (High seat position with optional ARH suspension):
- Static Ground Clearance: 145 mm (5.7 in.)
- Static Ground Clearance without ARH:
- Static Ground Clearance with ARH:
- Dynamic Ground Clearance (with optional suspension):
- Rake (steering head): 26
- Fork Angle: 29.25
- Trail: 173 mm (6.8 in.)
- Wheelbase: 1,625 mm (64 in.)
- Tires, Type: Dunlop® Harley-Davidson Series, bias blackwall front and rear
- Tires, Front Model: D408F
- Tires, Front Specification: 130/60B19 M/C 61H
- Tires, Rear Model: D407T
- Tires, Rear Specification: 180/55B18 M/C 80H
- Fuel Capacity: 22.7 l (6 gal.)
- Reserve Fuel Capacity, Fuel Injection (warning light): 3.8 l (1 gal.)
- Oil Capacity (w/filter): 4.7 l (5 qt.)
- Transmission Capacity: .95 l (1 qt.)
- Primary Chain Case Capacity: 1 l (1.1 qts.)
- Coolant Capacity: 0.78 l (0.82 qt.)
- Weight, As Shipped: 364 kg (802 lb.)
- Weight, In Running Order: 380 kg (838 lb.)
- Gross Vehicle Weight Rating: 617 kg (1,360 lb.)
- Gross Axle Weight Rating, Front: 227 kg (500 lb.)
- Gross Axle Weight Rating, Rear: 420 kg (927 lb.)
- Luggage Capacity -Volume: 0.069 m3 (2.42 cu ft)
- Engine: Milwaukee-Eight® 117
- Valves: Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; four valves per cylinder
- Bore: 103.5 mm (4.075 in.)
- Stroke: 114.3 mm (4.5 in.)
- Displacement: 1,923 cc (117.3491 cu in)
- Compression Ratio: 10.3:1
- Fuel System: Electronic Sequential Port Fuel Injection (ESPFI)
- Air Cleaner: Fiberglass, washable
- Exhaust: 2-1-2 dual exhaust with tapered mufflers
- Lubrication System: Pressurized, dry-sump
- Primary Drive: Chain, 34/46 ratio
- Final Drive: Belt, 32/68 ratio
- Clutch: Mechanically actuated 10 plate wet, Assist and Slip
- Transmission: 6-Speed Cruise Drive®
- Gear Ratios (overall) 1st: 9.593
- Gear Ratios (overall) 2nd: 6.65
- Gear Ratios (overall) 3rd: 4.938
- Gear Ratios (overall) 4th: 4
- Gear Ratios (overall) 5th: 3.407
- Gear Ratios (overall) 6th: 2.875
- Frame: Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin down-tubes; bolt-on rear frame with forged fender supports; MIG welded.
- Swingarm: Mild steel; two-piece drawn and welded section; forged junctions; MIG welded.
- Front Fork: 49mm (1.9 in) Dual Bending Valve
- Front Fork, Optional:
- Rear Shocks: 3 in. (76.2 mm) Dual Outboard Emulsion with Preload Adjustability
- Rear Shocks, Optional:
- Wheels, Optional Style Type: N/A
- Wheels, Front Type: Cast aluminum
- Wheels, Front Diameter: 19 in. (483 mm)
- Wheels, Front Width: 3.5 in. (89 mm)
- Wheels, Rear Type: Cast aluminum
- Wheels, Rear Diameter: 18 in. (457 mm)
- Wheels, Rear Width: 5 in. (127 mm)
- Brakes, Caliper Type: 32 mm (1.3 in.), 4-piston fixed dual axially mounted front, and single axially mounted rear
- Brakes, Rotor Type: Dual floating rotors (front), fixed rotor (rear)
- Brakes, Front Diameter: 320 mm (12.6 in.)
- Brakes, Front Thickness: 4.5 mm (0.18 in.)
- Brakes, Front is dual: Yes
- Brakes, Rear Diameter: 300 mm (11.8 in.)
- Brakes, Rear Thickness: 7 mm (0.28 in.)
- Brakes, Anti-Lock Braking System (ABS): Standard
- Suspension Travel, Front: 117 mm (4.6 in.)
- Suspension Travel, Rear: 76 mm (3 in.)
- Engine Torque Testing Method: J1349
- Engine Torque: 176 Nm (130 ft-lb)
- Engine Torque: 3,250
- Power: 105 HP / 78 kW @ 4600 rpm
- Lean Angle Testing Method: SAE J1168
- Lean Angle, Right: 32
- Lean Angle, Left: 32
- Fuel Economy Testing Method: EU 134/2014
- Fuel Economy: 6 l/100 km (39 mpg)
- CO2 Emissions Testing Method: EU 134/2014
- CO2 Emissions: 143 g/km CO2
- Stationary Noise: N/A
- Battery: Sealed, maintenance-free, 12V, 28-amp/hour, 405 cca (per Battery Council International Rating)
- Charging: Three-phase, 58-amp system (754W max power @ 13V)
- Starting: 1.6 kW electric with solenoid shift starter motor engagement
- Lights (as per country regulation), Headlamp: LED
- Lights (as per country regulation), Tail/Stop: LED
- Lights (as per country regulation), Front Signal Lights: LED
- Lights, Rear Turn Signals: LED
- Gauges: Digital gauges integrated within the display
- Auxiliary Lamps: N/A
- Electric Power Outlet: 15-Watt USB-C electric power accessory port in media storage box
- GPS System: Yes, embedded navigation system with real-time traffic and weather via Wi-Fi Hotspot (Subscription required in the US)
- Reverse: N/A
- Infotainment system: Skyline™ OS
- Screen Size: 12.3 in (312 mm)
- Type: Full Color TFT
- Watts Per Channel: 50
- Speakers: 2
- Speaker Size: Two 5.25 in. (133 mm) fairing speakers
- Headset Specifications (if equipped): N/A
- AM: Standard
- FM: Standard
- SD Card, Flash Drive and MP3 - via USB Connection: Supported
- Languages: Arabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese (Brazil/Portugal), Romanian, Russian, Siamese (Thai), Slovak, Spanish (Mexico/Spain), Swedish, Tagalog, Turkish, Vietnamese
- Hands-free Mobile Phone - via Bluetooth: Standard
- Voice Recognition Languages: Phone functions only: Phone dependent
- Voice Recognition Languages: Tuner/Media/Navigation: Danish, English (UK/USA default), French (Canada/France), German, Italian, Spanish (Mexico/Spain), Swedish
- Rider/Passenger Intercom: Rider and passenger headsets sold separately; VOX is available for H-D headsets
- Vehicle Information Screen (Air temperature, oil pressure and EITMS): Standard
- Text-to-Speech (TTS) Languages: Same as Languages list
- USB: USB-C/MTP/Smartphone will work with any phone which has proper adapters to the connection located in the inner fairing storage
- Phone Connectivity: Apple CarPlay (wireless or wired)
- Bluetooth: Phone/Media Player, Headset
- Navigation - via Bluetooth:
- Warranty: 24 months (unlimited mileage)
- Service Interval: First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter
Notes
Notes:
COMING SOON
Reserve your 2026 NOW
Warranty:
3-7 yrs Harley Davidson Extended Service Plan Available For Purchase
Promotion
