Overview
- Condition: New vehicle
- Manufacturer: Harley-Davidson
- Model: FLHLTSE
- Version: CVO STREET GLIDE 3 LIMITED
- Year: 2026
- Stock #: INS00065
- Type: Custom
- Exterior colour: CITRUS HEAT
Specifications
- Length: 2,685 mm (105.7 in.)
- Overall Width: 1,455 mm (56.3 in.)
- Overall Height: 1,435 mm (56.5 in.)
- Seat Height, Laden: N/A
- Seat Height, Laden (Low seat position):
- Seat Height, Laden (High seat position):
- Seat Height, Laden (Low seat position with optional ARH suspension):
- Seat Height, Laden (High seat position with optional ARH suspension):
- Seat Height, Unladen: 735 mm (28.9 in.)
- Seat Height, Unladen (Low seat position):
- Seat Height, Unladen (High seat position):
- Seat Height, Unladen (Low seat position with optional ARH suspension):
- Seat Height, Unladen (High seat position with optional ARH suspension):
- Static Ground Clearance: 130 mm (5.1 in.)
- Static Ground Clearance without ARH:
- Static Ground Clearance with ARH:
- Dynamic Ground Clearance (with optional suspension):
- Rake (steering head): 26
- Fork Angle: 32
- Trail: 96 mm (3.8 in.)
- Wheelbase: 1,720 mm (67.7 in.)
- Tires, Type: Dunlop® Harley-Davidson Series, bias blackwall front and radial blackwall rear
- Tires, Front Model: D408F
- Tires, Front Specification: 130/60B19 M/C 61H
- Tires, Rear Model: TK100
- Tires, Rear Specification: P215/45R18 83T
- Fuel Capacity: 22.7 l (6 gal.)
- Reserve Fuel Capacity, Fuel Injection (warning light): 3.8 l (1 gal.)
- Oil Capacity (w/filter): 4.7 l (5 qt.)
- Transmission Capacity: 1.15 l (1.22 qts.)
- Primary Chain Case Capacity: 1 l (1.1 qts.)
- Coolant Capacity: 0.78 l (0.82 qt.)
- Weight, As Shipped: 564 kg (1,243 lb.)
- Weight, In Running Order: 582 kg (1,283 lb.)
- Gross Vehicle Weight Rating: 771 kg (1,700 lb.)
- Gross Axle Weight Rating, Front: 232 kg (511 lb.)
- Gross Axle Weight Rating, Rear: 539 kg (1,189 lb.)
- Luggage Capacity -Volume: 0.201 m3 (7.1 cu ft)
- Engine: Milwaukee-Eight® VVT 121
- Valves: Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; four valves per cylinder
- Bore: 103.5 mm (4.075 in.)
- Stroke: 117.5 mm (4.625 in.)
- Displacement: 1,977 cc (121 cu in)
- Compression Ratio: 11.4:1
- Fuel System: Electronic Sequential Port Fuel Injection (ESPFI)
- Air Cleaner: Synthetic Felt, Washable
- Exhaust: 2-1-2 dual exhaust
- Lubrication System: Pressurized, dry-sump
- Drivetrain: FLHLTSE CVO™ Street Glide® 3 Limited
- Primary Drive: Chain, 34/46 ratio
- Final Drive: Belt, 30/70 ratio
- Clutch: Mechanically actuated 10 plate wet, Assist and Slip
- Transmission: 6 Speed Cruise Drive w/ Reverse
- Gear Ratios (overall) 1st: 10.534
- Gear Ratios (overall) 2nd: 7.302
- Gear Ratios (overall) 3rd: 5.423
- Gear Ratios (overall) 4th: 4.392
- Gear Ratios (overall) 5th: 3.742
- Gear Ratios (overall) 6th: 3
- Frame: Mild steel, square-section backbone with twin downtubes
- Swingarm: Permanent mold cast aluminum
- Front Fork: 1.9 in (49mm) dual bending valve
- Front Fork, Optional:
- Rear Shocks: Hand-adjustable emulsion rear suspension
- Rear Shocks, Optional:
- Wheels, Optional Style Type: N/A
- Wheels, Front Type: Dual Grain, Chrome, 14-spoke
- Wheels, Front Diameter: 19 in. (483 mm)
- Wheels, Front Width: 3.5 in. (89 mm)
- Wheels, Rear Type: Dual Grain, Chrome, 14-spoke
- Wheels, Rear Diameter: 18 in. (457 mm)
- Wheels, Rear Width: 7 in. (178 mm)
- Brakes, Caliper Type: Front: 32 mm 4 piston fixed, Rear: floating 36 mm piston integrated park brake
- Brakes, Rotor Type: Dual floating rotors (front), fixed rotor (rear)
- Brakes, Front Diameter: 300 mm (11.8 in.)
- Brakes, Front Thickness: 5 mm (0.197 in.)
- Brakes, Front is dual: Yes
- Brakes, Rear Diameter: 300 mm (11.8 in.)
- Brakes, Rear Thickness: 7 mm (0.276 in.)
- Brakes, Anti-Lock Braking System (ABS): Standard
- Suspension Travel, Front: 117 mm (4.6 in.)
- Suspension Travel, Rear: 88 mm (3.46 in.)
- Engine Torque Testing Method: J1349
- Engine Torque: 187 Nm (138 ft-lb)
- Engine Torque (rpm): 3,750
- Power: 114 HP / 85 kW @ 4500 rpm
- Lean Angle Testing Method: N/A
- Lean Angle, Right (deg.): N/A
- Lean Angle, Left (deg.): N/A
- Fuel Economy Testing Method: EU 134/2014
- Fuel Economy: 7.1 l/100 km (33 mpg)
- CO2 Emissions Testing Method: EU 134/2014
- CO2 Emissions: 168 g/km CO2
- Stationary Noise (BRZ only): N/A
- Battery: Sealed, maintenance-free, 12V, 28-amp/hour, 405 cca (per battery Council International Rating)
- Charging: Three Phase, 48-amp system (600W@13V, 2000 rpm, 625W max power @ 13V)
- Starting: 1.6kW electric with solenoid shift starter motor engagement
- Lights (as per country regulation), Headlamp: LED
- Lights (as per country regulation), Tail/Stop: LED
- Lights (as per country regulation), Front Signal Lights: LED
- Lights, Rear Turn Signals: LED
- Gauges: Digital gauges integrated within the display
- Auxiliary Lamps: LED Fog Lamps integrated into Lower Fairings
- Electric Power Outlet: 15 Watt USB-C electric power accessory port in media storage box
- GPS System: Yes, embedded navigation system with real-time traffic and weather via Wi-Fi Hotspot
- Reverse: Electric reverse actuated by handlebar mounted hand controls
- Infotainment system: Skyline™ OS
- Screen Size: 12.3 in (312 mm)
- Type: Full Color TFT
- Watts Per Channel: 125 (4) & 150 (2)
- Speakers: 6
- Speaker Size: Two 6.5 in. (165 mm) fairing speakers, two 6.5 in. (165 mm) Tour-pak speakers, and two 6.5 in. (165 mm) lower fairing speakers
- Headset Specifications (if equipped): Harley-Davidson® Packtalk Edge wireless Bluetooth® headset
- AM: Standard
- FM: Standard
- MW: N/A
- LW: N/A
- Weather Band (WB): N/A
- SD Card, Flash Drive and MP3 - via USB Connection: Supported
- Languages: Arabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese (Brazil/Portugal), Romanian, Russian, Siamese (Thai), Slovak, Spanish (Mexico/Spain), Swedish, Tagalog, Turkish, Vietnamese
- Hands-free Mobile Phone - via Bluetooth: Standard
- Voice Recognition Languages: Phone functions only: Phone dependent
- Voice Recognition Languages: Tuner/Media/Navigation: Danish, English (UK/USA default), French (Canada/France), German, Italian, Spanish (Mexico/Spain), Swedish
- Rider/Passenger Intercom: Standard (Passenger Headset Sold Separately); VOX is available for H-D headsets
- Vehicle Information Screen (Air temperature, oil pressure and EITMS): Standard
- Text-to-Speech (TTS) Languages: Same as Languages list
- USB: USB-C/MTP/Smartphone will work with any phone which has proper adapters to the connection located in the inner fairing storage
- Phone Connectivity: Apple CarPlay (wireless or wired)
- Bluetooth: Phone/Media Player, Headset
- Navigation - via Bluetooth:
